Ta'rif
Avlod 2 Chm-14 CAB qatorlari Oq LED
Luminus chip - - Campe (CAB) LED seriyasi yuqori darajadagi yoritilish dasturlari uchun mo'ljallangan to'liq yoritish klassi echimini taklif etadi. Selektsiya 400 ml dan kam bo'lgan keng lümen oralig'ini, 97 va 3000k va R9 95 ga teng. Ushbu taniqlar 97 va 3000 va R9 95 ga teng.
Xususiyatlari
• Yuqori lümen chiqish va samaradorligi odatiy
• 3,200 lm dan ortiq, 128 lpw @ 3000k, 85ºC
• 3,700 lm, 147 lpw @ 5000k, 85ºC
• CCT oralig'idagi 2700k, 3000k, 3500k, 4000k, 5000k, 5000k, 5000k, 6500k
• 80 yoki 90 CRI min. 95 daqiqagacha. yuqori r9 bilan issiq oq rangda
• 3 SDCM rangini o'chirish aniqligi
• Ajoyib optik emissiya bir xilligi va izchilligi bo'yicha ranglar
• uzoq vaqt davomida rang barqarorligi
• Yagona issiqlik tarqalishi uchun yuqori issiqlik o'tkazuvchanligi
• ekologik toza: rohs va mos keladi
Arizalar
• Displeylar / trek chiroqlari
• Yengil yoritgichlar
• do'kon yoritish
• mehmondo'stlik yoritish
• Arxitektura va mutaxassislik
• ko'cha yoritish
• Avtomobil to'xtash joyi va maydonni yoritish
• Tunnel yoritish
Rang Harorat, kri va r9 Qadriyatlar
|
Rang Harorat |
Xx Qiymati |
Jovar |
R9 |
|
4000K, 5000K, 6500K |
70 |
>70 |
- |
|
2700K, 3000K, 3500K, 4000K, 5000K, 6500K |
80 |
>80 |
>0 |
|
2700K, 3000K, 3500K, 4000K, 5000K |
90 |
>90 |
>50 |
|
2700K, 3000K |
95 |
>95 |
>85 |
|
3500K |
>80 |
Chm-14 Qism Raqamlar (Aa10)
Quyidagi jadvallar odatiy oqilon va minimal oqim bilan 720ma bilan o'lchanadi va=85 ºC da ko'rsatilgan. 25ºC da qiymatlar hisoblab chiqilgan va faqat ma'lumot uchun ko'rsatilgan.
|
Chiqindi Flux (lm) |
Ma'lumotnoma |
Rang Bildirish Indeks |
Buyurtma berish qismi Raqam |
||
|
Kct |
Taom. (85ºC) |
Min. (85ºC) |
Taom. (hisoblangan) (25ºC) |
Jovar (min.) |
3-qadam Makadasi Ellips |
|
2700K |
2,980 |
2,771 |
3,405 |
80 |
Chm-14-27-80-36-aa10-f3-3 |
|
2,415 |
2,245 |
2,655 |
90 |
Chm-14-27-90-36-aa10-f3-3 |
|
|
2,275 |
2,115 |
2,500 |
95 |
Chm-14-27-95-36-aa10-f3-3 |
|
|
3000K |
3,150 |
2,930 |
3,590 |
80 |
Chm-14-30-80-36-aa10-f3-3 |
|
2,700 |
2,511 |
3,055 |
90 |
Chm-14-30-90-36-aa10-f3-3 |
|
|
2,480 |
2,306 |
2,830 |
95 |
Chm-14-30-95-36-AA10-F3-3 |
|
|
3500K |
3,280 |
3,050 |
3,720 |
80 |
Chm-14-35-80-36-aa10-f3-3 |
|
2,800 |
2,604 |
3,170 |
90 |
Chm-14-35-90-36-aa10-f3-3 |
|
|
2,590 |
2,409 |
2,925 |
95 |
Chm-14-35-95-36-AA10-F3-3 |
|
|
4000K |
3,330 |
3,097 |
3,850 |
80 |
Chm-14-40-80-36-aa10-f3-3 |
|
2,850 |
2,651 |
3,270 |
90 |
Chm-14-40-90-36-aa10-f3-3 |
|
|
Chiqindi Flux (lm) |
Ma'lumotnoma |
Rang Bildirish Indeks |
Qism Raqam |
|||
|
Kct |
Taom. (85ºC) |
Min. (85ºC) |
Taom. (hisoblangan) (25ºC) |
Jovar (min.) |
5-qadam Makadasi Ellips |
3-qadam Makadasi Ellips |
|
5000K |
3,360 |
3,125 |
3,940 |
80 |
Chm-14-50-80-36-aa10-f3-5 |
ChM-14-50-80-36-AA10-F3-3 |
|
6500K |
3,360 |
3,125 |
3,925 |
80 |
ChM-14-65-80-36-AA10-F3-5 |
Chm-14-65-80-36-aa10-f3-3 |
Chm-14 Qism Raqamlar (O'tkir10)
Quyidagi jadvallar tipik oqim va minimal oqim bilan 720mada o'lchangan va 85ºC da ko'rsatilgan minimal oqim bilan tavsiflangan. 25ºC da qiymatlar hisoblab chiqilgan va faqat ma'lumot uchun ko'rsatilgan. Barcha mahsulot 85ºSement haroratida o'lchanadi va belgilangan
|
Chiqindi Flux (lm) |
Ma'lumotnoma |
Rang Bildirish Indeks |
Buyurtma berish qismi Raqam |
||
|
Kct |
Taom. (85ºC) |
Min. (85ºC) |
Taom. (hisoblangan) (25ºC) |
Jovar (min.) |
3-qadam Makadasi Ellips |
|
2700K |
2,980 |
2,771 |
3,405 |
80 |
Chm-14-27-80-36-AC10-F3-3 |
|
2,415 |
2,245 |
2,655 |
90 |
Chm-14-27-90-36-AC10-F3-- |
|
|
2,275 |
2,115 |
2,500 |
95 |
Chm-14-27-95-36-AC10-F3-3 |
|
|
3000K |
3,150 |
2,930 |
3,590 |
80 |
ChM-14-30-80-36-AC10-F3-3 |
|
2,700 |
2,511 |
3,055 |
90 |
Chm-14-30-90-36-AC10-F3-3 |
|
|
2,480 |
2,306 |
2,830 |
95 |
ChM-14-30-95-36-AC10-F3-3 |
|
|
3500K |
3,280 |
3,050 |
3,720 |
80 |
Chm-14-35-80-36-AC10-F3-- |
|
2,800 |
2,604 |
3,170 |
90 |
Chm-14-35-90-36-AC10-F3-3 |
|
|
4000K |
3,675 |
3,415 |
4,045 |
70 |
Chm-14-40-70-36-AC10-F3-3 |
|
3,330 |
3,097 |
3,850 |
80 |
ChM-14-40-80-36-AC10-F3-3 |
|
|
2,850 |
2,651 |
3,270 |
90 |
ChM-14-40-90-36-AC10-F3-3 |
|
|
2,760 |
2,565 |
3,035 |
95 |
Chm-14-40-95-36-AC10-F3-3 |
|
|
Chiqindi Flux (lm) |
Ma'lumotnoma |
Rang Bildirish Indeks |
Qism Raqam |
|||
|
Kct |
Taom. (85ºC) |
Min. (85ºC) |
Taom. (hisoblangan) (25ºC) |
Jovar (min.) |
5-qadam Makadasi Ellips |
3-qadam Makadasi Ellips |
|
5000K |
3,760 |
3,495 |
4,135 |
70 |
ChM-14-50-70-36-AC10-F3-5 |
ChM-14-50-70-36-AC10-F3-3 |
|
3,360 |
3,125 |
3,940 |
80 |
Chm-14-50-80-36-AC10-F3-5 |
Chm-14-50-80-36-AC10-F3-3 |
|
|
6500K |
3,745 |
3,480 |
4,120 |
70 |
ChM-14-65-70-36-AC10-F3-5 |
ChM-14-65-70-36-AC10-F3-3 |
|
3,360 |
3,125 |
3,925 |
80 |
ChM-14-65-80-36-AC10-F3-5 |
ChM-14-65-80-36-AC10-F3-3 |
|
Chm-14 Ishlamoq Yaroqlilikestra1
Optik va elektr xususiyatlari
|
Parametr |
Belgi |
Minimal |
Odatiy |
Maksimal |
Birlik |
|
Oldindan oldinga |
Agar |
720 |
1,440 |
mayin |
|
|
Oldinga kuchlanish3 |
Vf |
33.5 |
35.5 |
37.5 |
V |
|
Kuch |
25.5 |
52 |
W |
||
|
Ish holatidagi harorat |
T c |
105 |
ºC |
||
|
Yorug'lik chiqaradigan sirt diametri |
Les |
13.5 |
mm |
||
|
Issiqona qarshilik ({- misol) |
Nobud |
0.45 |
ºC/W |
||
|
Tarmoq harorati |
Tj |
140 |
ºC |
||
|
Ko'rish burchagi |
120 |
Daraja |
