Ta'rif
SST-10-ARD-810NM
Dual birikma yuzasi seriyali
Kam termal qarshilik infradem LED
Xususiyatlari
• Yuqori quvvat infrumemed LED-da, o'rtacha 810 nm Centroid to'lqin uzunligi
• Yuqori issiqlik o'tkazuvchanligi substrati
• 90 va 130 daraja ko'rish burchagi
• 1,5 tagacha CW va 5 ta pulse
• Korroziya mustahkamligi sinfi: 3b
• ESD himoyasida - qurildi
• Kam termal qarshilik
• Barcha SMT yig'ish usullari uchun mos
Arizalar
• Nazorat tizimlari / CCTV
• Iris va Yolg'on tan olish
• Litsenziya plitasi skanerlash
• Avtomobilsozlik hissi
• Mashinani ko'rish
• tungi ko'rish
Qism raqamlarini buyurtma qilish
|
Cho'qqili to'lqin uzunligi |
Radiometrik oqim |
Ko'rish burchagi |
Qism raqami buyurtma |
|
|
Minimal Flux ibn |
Minimal Flux |
|||
|
810 nm |
S |
475 mw |
90 |
SST - 10 - IRD-B90H-S810 |
|
130 |
SST - 10 - IRD-B130H-S810 |
|||
Radiometrik flux bitlari1
|
Flux ibn |
@ 350 ma, TC =25 1 |
|
|
Minimal flux (mw) |
Maksimal Flux (MW) |
|
|
S |
475 |
505 |
|
T |
505 |
535 |
|
U |
535 |
565 |
|
V |
565 |
595 |
|
W |
595 |
625 |
|
X |
625 |
655 |
|
Y |
655 |
685 |
|
Z |
685 |
715 |
Oldinga ellik kuchlanish2
|
Kuchlanish qutisi |
3-550 MA, TC=25 ilmiy darajali |
|
|
Minimal kuchlanish (v) |
Maksimal kuchlanish (v) |
|
|
V9 |
2.8 |
3.0 |
|
Va |
3.0 |
3.2 |
|
Tiniq |
3.2 |
3.4 |
Cho'qqini to'lqin uzunligi
|
To'lqin uzunligi qutisi |
3-550 MA, TC=25 ilmiy darajali |
|
|
Minimal to'lqin uzunligi (nm) |
Maksimal to'lqin uzunligi (nm) |
|
|
810 |
800 |
830 |
Xususiyatlar1
|
Parametr (agar {=350 MA, TC =25 |
Belgi |
Qiymati |
Birlik |
|
|
Oldinga oldinga |
Agar |
350 |
mayin |
|
|
Oddiy chiqish quvvat |
φv |
535 |
mw |
|
|
Oddiy chiqish quvvat @ 1.0A, t=20 ms |
φv 1.0A |
1470 |
mw |
|
|
Oldinga kuchlanish |
Minimal |
Vf min |
2.8 |
V |
|
Odatiy |
VF TURING |
3.0 |
||
|
Maksimal |
Vf max |
3.4 |
||
|
Ko'rish burchagi |
B90H |
2 Ø1/2 |
90 |
daraja |
|
B130H |
130 |
|||
|
Yorqin intensivlik @ 1.0A, t {= 20 ms |
B90H |
FE TO |
770 |
mw / sr |
|
B130H |
410 |
|||
|
Cho'qqili to'lqin uzunligi |
λp |
815 |
nm |
|
|
Centroid to'lqin uzunligi |
λc |
810 |
||
|
Finchi |
∆λ1/2 |
30 |
||
|
Voltajning harorat koeffitsienti |
DVF / DT |
-3.0 |
mv / daraja |
|
|
Radiometrik quvvat koeffitsienti |
∆Φ/∆T |
-0.2 |
% / darajasi |
|
|
To'lqin uzunligining harorat koeffitsienti |
∆λ/ ∆T |
0.3 |
nm / daraja |
|
|
Elektr termal qarshilik (lehim nuqtai nazaridan kesish) 2 |
Rt JS Elek |
2.4 |
daraja / w |
|
